Philippi branch bolt holder 1-pole, holder for bolt fuses, max. 300A and 58V DC, for battery mounting

Type Philippi ABH 1

The ABH 1 holder, specially designed for the SHB bolt fuses, enables the use of the space-saving SHB bolt fuses (MRBF = Marine rated bolt fuses) thanks to the insulated bolt.

For mounting on battery terminals with a 10mm screw diameter. Matching cable lugs with an 8mm hole diameter.

Maximum operating voltage: 58V DC

Maximum current load: 300A

Maximum torque: 8.5 Nm

Threaded bolt: M8

• Suitable for fuse type SHB (MRBF)
